SIKU BESI

Name: Siku Besi SS400 Galvanis
Brand: Siku Besi SS400 Galvanis
Availability: InStock

Produk Besi / Siku Besi

Siku Besi SS400 Galvanis

SIKU BESI SS400 GALVANIS

JUAL SIKU BESI GALVANIS SS400 , EQUAL ANGLE BAR GALVANIZE SS400 , EQUAL ANGLE BARS (SNI 07-2054-2006 EQUIVALENT TO JIS G - 3101 AND 3192)

Kode

ITM00452

Merk

LOKAL

Deskripsi Produk

JUAL SIKU BESI GALVANIS SS400 , EQUAL ANGLE BAR GALVANIZE SS400 , EQUAL ANGLE BARS (SNI 07-2054-2006 EQUIVALENT TO JIS G - 3101 AND 3192)

Length : 6 m, 9 m and 12 m
Standards : SNI 07-2054-2006, JIS G 3101 and G 3192, AS/NZS3679.1 and BS EN10025

General Structure properties eq. with JIS G 3101

Grade	Chemical Composition (%)				Tensile Test
	C (max.)	Mn (max.)	P (max.)	S (max.)	Yield Strength (N/mm²)				Tensile Strength (N/mm²)	Elongation
					Thickness (mm)					Thickness (mm)	Test Piece	% (min.)
					t≤16	16	40	t>100		Thickness (mm)	Test Piece	% (min.)
SS400	-	-	0.05	0.05	245 min.	235 min.	215 min.	205 min.	400 - 510	6≤t≤16	No. 1A	17
										16	No. 1A	21
										40	No.4	23
SS540	0.30	1.60	0.04	0.04	400 min.	390 min.	-	-	540 min.	6≤t≤16	No. 1A	13
SS540	0.30	1.60	0.04	0.04	400 min.	390 min.	-	-	540 min.	16	No. 1A	17

General Structure properties as per SNI 07-2054-2006

de	Chemical Composition (%)				Tensile Test
	C (max.)	Mn (max.)	P (max.)	S (max.)	Yield Strength (N/mm²)				Tensile Strength (N/mm²)	Elongation
					Thickness (mm)					Thickness (mm)	Test Piece	% (min.)
					t≤16	16	40	t>100		Thickness (mm)	Test Piece	% (min.)
SS400	-	-	0.05	0.05	245 min.	235 min.	215 min.	205 min.	400 - 510	6≤t≤16	No. 1A	17
										16	No. 1A	21
										40	No.4	23
SS540	0.30	1.60	0.04	0.04	400 min.	390 min.	-	-	540 min.	6≤t≤16	No. 1A	13
SS540	0.30	1.60	0.04	0.04	400 min.	390 min.	-	-	540 min.	16	No. 1A	17

Size Standard sectional dimension

Ukuran	Berat
25 x 25 x 3 mm x 6 M	6,72 kg
30 x 30 x 3 mm x 6 M	8,16 kg
40 x 40 x 3 mm x 6 M	11,- kg
40 x 40 x 4 mm x 6 M	14,50 kg
50 x 50 x 4 mm x 6 M	18,50 kg
50 x 50 x 5 mm x 6 M	22,60 kg
60 x 60 x 5 mm x 6 M	27,3 kg
60 x 60 x 6 mm x 6 M	32,52 kg
65 x 65 x 6 mm x 6 M	35,46 kg
70 x 70 x 7 mm x 6 M	44,28 kg
75 x 76 x 6 mm x 6 M	41,28 kg
75 x 75 x 9 mm x 6 M	59,8 kg
80 x 80 x 8 mm x 6 M	57,96 kg
