CHEMICAL COMPOSITION |
|
| Element | Percentage |
| C | 0.26 |
| Cu | 0.2 |
| Fe | 99 |
| Mn | 0.75 |
| P | 0.04 max |
| S | 0.05 max |
MECHANICAL INFORMATION |
||
| Imperial | Metric | |
| Density | 0.282 lb/in3 | 7.8 g/cc |
| Ultimate Tensile Strength | 58,000psi | 400 MPa |
| Yield Tensile Strength | 47,700psi | 315 MPa |
| Shear Strength | 43,500psi | 300 MPa |
| Melting Point | 2,590 - 2,670°F | 1,420 - 1,460°C |
| Hardness Brinell | 140 |
| Production Method | Hot Rolled |
SIZES |
||
| Size | Length | Weight (lbs/ft) |
| 1/8" x 1/2" | 240.00" | 0.213 |
| 1/8" x 5/8" | 240.00" | 0.266 |
| 1/8" x 3/4" | 240.00" | 0.319 |
| 1/8" x 7/8" | 240.00" | 0.372 |
| 1/8" x 1" | 240.00" | 0.425 |
| 1/8" x 1-1/4" | 240.00" | 0.531 |
| 1/8" x 1-1/2" | 240.00" | 0.638 |
| 1/8" x 1-3/4" | 240.00" | 0.744 |
| 1/8" x 2" | 240.00" | 0.850 |
| 1/8" x 2-1/2" | 240.00" | 1.060 |
| 1/8" x 3" | 240.00" | 1.280 |
| 1/8" x 3-1/2" | 240.00" | 1.490 |
| 1/8" x 4" | 240.00" | 1.700 |
| 1/8" x 4-1/2" | 240.00" | 1.913 |
| 1/8" x 5" | 240.00" | 2.125 |
| 1/8" x 6" | 240.00" | 2.550 |
| 1/8" x 8" | 240.00" | 3.333 |
| 1/8" x 10" | 240.00" | 4.250 |
| 1/8" x 12" | 240.00" | 5.000 |
| 3/16" x 1/2" | 240.00" | 0.319 |
