CHEMICAL COMPOSITION |
|
| Element | Percentage |
| C | 0.26 |
| Cu | 0.2 |
| Fe | 99 |
| Mn | 0.75 |
| P | 0.04 max |
| S | 0.05 max |
MECHANICAL INFORMATION |
||
| Imperial | Metric | |
| Density | 0.282 lb/in3 | 7.8 g/cc |
| Ultimate Tensile Strength | 58,000psi | 400 MPa |
| Yield Tensile Strength | 47,700psi | 315 MPa |
| Shear Strength | 43,500psi | 300 MPa |
| Melting Point | 2,590 - 2,670°F | 1,420 - 1,460°C |
| UKURAN | BERAT |
|---|---|
| 4,5 mm x 6’ x 20’ | 394 kg |
| 6 mm x 6’ x 20’ | 525 kg |
| 8 mm x 6’ x 20’ | 700 kg |
| 9 mm x 6’ x 20’ | 788 kg |
| 10 mm x 6’ x 20’ | 875 kg |
| 12 mm x 6’ x 20’ | 1050 kg |
| 16 mm x 6’ x 20’ | 1400 kg |
| 19 mm x 6’ x 20’ | 1664 kg |
| 22 mm x 6’ x 20’ | 1926 kg |
| 25 mm x 6’ x 20’ | 2188 kg |
